Product Details of Spin Air 7.4 kW EV Charger in Nepal:
- Charging Power: 7.4 kW (Single-phase)
- Max. AC Output Current: 32 A
- Connection Point / Plug Type: IEC 62196-2 Type-2 (Tethered 5 meters)
- Mode of Charging: Mode-3
- Operating Temperature Range: -25°C to 55°C (full power); Storage: -40°C to 75°C
- Protection Ratings: IP66 (Ingress Protection) | IK10 (Impact Resistance)
- Construction & Material: Polycarbonate + ABS (UL94-V0)
- Dimensions (H×W×D): 246 × 246 × 113 mm | Weight: ~7.5 kg (incl. cable)
- Integrated Safety / Residual Current: 6mA DC + 30mA AC leakage detection
- Communication: OCPP v1.6J, Bluetooth/Wi-Fi/4G, OTA software updates
- Altitude: Rated up to 2,000m — performance derates above this altitude
- Certifications & Standards: Safety: IEC 61851-1 | Other: CE, IEC 61851-21-2, IEC 62196-1, IEC 62196-2, IEC 61000, ARAI (IS 17017 series)
Features
Universal Fleet Compatibility
Equipped with a standard Type-2 (IEC 62196-2) tethered 5-meter cable designed to power all modern electric vehicles efficiently.
High-Efficiency Rapid Charging
Delivers a robust 32 A output at 7.4 kW (1-phase) for powerful home or light commercial charging.
Smart App & Integration Control
Features intuitive remote scheduling, real-time analytics, and voice control capabilities via Bluetooth, Wi-Fi, 4G, Amazon Alexa, and Google Home. Manage your home EV charger setup (7.4 kW) from anywhere.
Download: iOS | Android
Smart Load Management & Sharing
Automatically adjusts charging current in 1A steps to prevent overloads on your home’s electrical supply. With the optional SpinNet system, power can be shared across multiple chargers and prioritized from rooftop solar generation.
Heavy-Duty Rugged Construction
Built using fire-retardant polycarbonate + ABS (UL94-V0) with an extreme IK10 structural impact resistance rating.
All-Weather Operational Resilience
Boasts an outstanding IP66 weatherproof rating, allowing it to remain fully operational in extreme outdoor temperatures ranging from -25°C to 55°C — reliable across Nepal’s monsoon and hill climates.
Advanced Multi-Layer Safety Protection
Outfitted with integrated 6 mA DC + 30 mA AC leakage detection, alongside over-current, under/over-voltage, and over-temperature safety safeguards.
Plug & Play Authentication
Supports RFID/NFC (MIFARE ISO/IEC14443 A) authentication alongside app-based control, with MID-compliant energy metering for accurate usage tracking.
Certified Global Benchmarks
Complies stringently with IEC 61851-1 safety standards, CE, and ARAI certifications — the same standard used across Exicom’s 150,000+ installations.
7.4 kW AC EV Charger Price in Nepal
HITCO sells a 7.4 kW AC EV charger in Nepal for NPR 65,000. Call +977 985-1253028 or message us on WhatsApp to check current stock.
Specifications
Power Output
- Charging Power: 7.4 kW (Single-phase)
- AC Output: 90–265 VAC (per phase)
- Connection Point / Plug Type: IEC 62196-2 Type-2 (tethered 5 meters)
- Mode of Charging: Mode-3
- Max. AC Output Current: 32 A
Main Input
- Input Voltage (nominal): 220/230/240 VAC
- Input Voltage Range: 90–265 VAC (per phase)
- Network Connection: TN-S
- AC Wiring: 1 Phase / L1, N, PE
- Input Frequency (nominal): 50 / 60 Hz
- Input Frequency Range: 45–65 Hz
- Leakage Current: < 3.5 mA
- Standby Power @ nominal voltage: < 10 W
Protection and Safety
- Di-electric Strength Test: 4,000 Vac (common mode) or 2,500 Vac (differential)
- Impulse Di-electric Withstand (1.2/50 µs): 6,000 Vac (common mode) or 4,000 Vac (differential)
- Insulation Resistance: IR > 10 MΩ
- Over Voltage Category: II
- Residual Current: Integrated Type-B 6 mA DC (to IEC 62955) + 30 mA AC (external Type-A RCD recommended)
- Additional Protection: Over Current, Under/Over Voltage, Over Temperature, Ground-Neutral Voltage, Residual Current Detection
User Interface and Comms
- Charge Option / Authentication: Plug & Play, RFID/NFC MIFARE (ISO/IEC14443 A), via Spin Control app or 3rd-party CMS
- Connectivity Options: Bluetooth, Wi-Fi, or 4G modem
- Smart Home Integration: Amazon Alexa, Google Home
- Visual Indication (LED): Presence of Supply, State of Charging, Error
- Communication (EVSE–CMS): OCPP v1.6 J (JSON)
- Energy Metering: Integrated (MID-compliant option available)
Configuration
- Software Update: OTA (Over The Air)
- Control, Set-up & Monitoring: OCPP v1.6j, Exicom Spin Control app
Load Management
- Manual Max Load Limiting: 1A steps (via Spin Control app)
- Dynamic Management: Load curtailment; solar export control (optional SpinNet system)
- Load Sharing: Up to 31 chargers (optional SpinNet system)
Mechanical
- Ingress Protection: IP66 (Outdoor rated)
- Impact Resistance: IK10 (per IEC 62262)
- Dimensions (H×W×D): 246 × 246 × 113 mm
- Weight: ~7.5 kg (incl. cable)
- Charging Cable Length: Tethered 5 meters (other lengths optional)
- Cable Storage: Wraps around charger body with gun-holster mount
- Construction & Material: Polycarbonate + ABS (UL94-V0)
- Mounting: Pedestal stand or wall
- Cooling: Natural air
Environmental
- Operating Temperature: -25°C to 55°C (full power)
- Storage Temperature: -40°C to 75°C
- Altitude: Rated up to 2,000 m (performance derates above this altitude)
- Humidity (Non-Condensing): 5%–95%
Standards / Certification
- Safety: IEC 61851-1
- Other: CE, IEC 61851-21-2, IEC 62196-1, IEC 62196-2, IEC 61000, ARAI (IS 17017 series)
FAQ's
What is the price of a 7.4 kW EV charger in Nepal?
The Exicom Spin Air 7.4 kW EV charger costs NRS 65,000 in Nepal. Contact Hitco to confirm the latest price.
Where can I buy an Exicom 7.4 kW EV charger in Nepal?
From Hitco Pvt Ltd, the authorized supplier of Exicom EV charger in Nepal. Hitco also supports professional installation.
Is the Spin Air a single phase or three phase EV charger?
The Spin Air 7.4 kW AC EV charger model sold by HITCO is a single phase, delivering up to 32A continuous output suited to standard Nepali residential electrical connections.
Is a 7.4 kW home EV charger enough for daily charging in Nepal?
Yes. A 7.4 kW home EV charger typically adds roughly 35-45 km of range per hour of charging (depending on the vehicle), which is more than enough to fully charge most EVs overnight from a standard single-phase home connection.
Which EVs can use the Exicom Spin Air 7.4 kW charger?
Any EV with a Type-2 AC charging port. The charger has a 5-meter tethered Type-2 cable and Mode-3 charging.
How long does a 7.4 kW EV charger take to charge a car?
It depends on your battery size and your car’s onboard charger. As a rough guide, 7.4 kW adds about 7 kWh per hour, so a 40 kWh battery takes around 5 to 6 hours from empty. Some cars accept less than 7.4 kW on AC, which makes charging slower.
Can I install a 7.4 kW EV charger at home in Nepal?
Yes, if your home has a single phase supply that can handle 32 A. Installation should be done by a professional, and Hitco can check your electrical setup first. Exicom also recommends an external Type-A RCD.
Is the Exicom Spin Air safe to use outdoors?
Yes. It has an IP66 rating for dust and water protection and IK10 impact resistance. It runs at full power from -25°C to 55°C.
Can 7.4 kW AC EV charger be installed outdoors?
Yes, it features an outstanding IP66 weatherproof rating and an IK10 impact resistance rating, making it highly durable for both indoor and outdoor setups across Nepal’s varied climate.
What is the maximum charging speed and output power?
The charger delivers a maximum charging power of 7.4 kW on a single-phase supply with a maximum output current of 32 A.
Does this charger work at high altitude?
The Spin Air is rated for full performance up to 2,000 meters altitude. Above this, output may derate slightly worth mentioning to HITCO if you’re installing in a higher hill location so they can advise accordingly.
Does it have smart app control?
Yes, you can control, schedule, and track real-time analytics using the companion smart app via Bluetooth, Wi-Fi, or 4G connectivity.
Is the 7.4 kW AC EV charger the genuine Exicom product with local warranty support?
Yes. HITCO is an authorized supplier of the genuine Exicom Spin Air, with local warranty and after-sales service support based in Kathmandu.
